PRODUCT CHARACTERISTICS

TCM TERMO SHIELD liquid applied insulation is a premium industrial grade rust proofing protective insulation coating containing Hydro-NM-Oxide, which is the best insulating material on the planet...by far. Thermal Conductivity: W/m-K=0.018 at 25 Degrees Celsius. TCM TERMO SHIELD™, when fully cured, contains a high level of Hydo-NM-Oxide along with acrylic resin and performance additives. It has unique and astounding insulation properties which surpass all other forms of insulation previously available. TCM Termo Shield has proven resistance to both existing mold growth and new mold growth. TCM Termo Shield can also be used for Lead Abatement—as a lead encapsulation coating. 20 year warranty.Pipes, Tanks, Trucks, Textile, Attics, Walls, Ships, Automotive, Containers, Residential, Commercial, IndustrialCorrosion protection and insulation are now combined into one, solving the costly problem of CUI (corrosion under insulation).

Excellent adhesion to a wide variety of substrates.

User-friendly with no special tools needed and easy to apply.

Effective three-coat system, which can be easily over-coated if desired.

Ability to see the substrate through the material allows for visual inspection of pipes, tank and equipment.

Mold resistance without use of potentially harmful anti-fungal agents

Encapsulate Lead with a smooth, water-based, environmentally friendly coating.Available TCM Termo Shield Translucent products:TCM Termo Shield

Translucent PT & GP:
Temp range (after cure) –40°C to 125°C (–40°F to 257°F)

TCM Termo Shield Translucent High Heat:
Temp range (after cure) –40°C to 204°C (–40°F to 400°F)
Application Temperature range: 4°C to 100°C (40°F to 212°F)

PRODUCT DESCRIPTION
Liquid insulation and corrosion protection incorporating Hydro-NM-Oxide, a product of Nanotechnology.

PRODUCT INFORMATION
Color: Translucent
Container Sizes: 1 gallon, 5 gallon
Viscosity, cps: 3500-4000
Density, lb/gal: 8.5
Weight Solids, % 32 (+ or - 2%)
Volume Solids, % 30.0 (+ or - 2%)
Touch Dry: 1-2 Hours
Hard Dry (return to service): 24-48 hours
Full Cure: 30-60 days
Typical thickness range: 76.2—127 microns per coat
Theoretical coverage: @ 1 mil, Ft² 1600

APPLICATION DATA

Application Method: Airless spray, Brush, Roll
Equipment Settings: Adjust air pressure for a consistent film thickness.
Applied Over: In exterior applications, use over suitable primer
Recommended Reduction: Reduction is not recommended, however slight reduction done if needed for a specific application.
Reducer: Water
Reduced Viscosity: As needed for application
Recommended Film Thickness: Per coat:
Wet: 3-5 mils (76.2-127 microns)
Dry: 1.5-2.5 mils (38.1-63.5 microns)
Precautions: Do not apply thicker than recommended film thickness.

SURFACE PREPARATION

Metallic Surfaces: Remove all loose contamination by wire brushing.
Remove all dirt, grease, oil, soluble salts and other contamination by using a suitable cleaner/degreaser and clean water rinse.
Remove all loose, flaking rust and/or paint by Hand Tool Clean or Power Tool Clean. Commercial Blast Clean may be done. If this method is selected then the profile shall be 1-1.5 mils in depth and angular in appearance.
Painted Surfaces: Ensure paint is not flaking or peeling.
Remove all loose dirt, oil, grease or other contaminate.
Abrade the surface prior to TCM Termo Shield application.
Other Surfaces: Remove all loose contamination by wire brushing.
Remove any dirt, oil, grease, etc. using a suitable cleaner/degreaser that does not leave a residue.

SAFETY PRECAUTIONS
Follow all MSDS/label precautions even after container is emptied because it may retain product residues. Avoid contact with skin and eyes.

STORAGE
Store in cool, dry conditions (between 2—20°C (36—68°F)). Keep away from direct heat source.

When not using the material, always replace the lid on the container.
Do not freeze.

SHELF LIFE
Up to 12 months stored in sealed containers at temperatures between 2—20°C (36—68°F).
